Full Color SMD3528 Perimeter led display outdoor / Sports advertising led screen Waterproof



Full Color SMD3528 Perimeter led display outdoor / Sports advertising led screen Waterproof





Quick Details:



1. Top Cabinet Special Design for Collision Avoidance.



2. Adjustable Soleplate Design, Cabinet Freely Regulated Angle 55°to 90°.



3. Back door and Cabinet Façade parallel, Simple and Practical.



4. Stowable Regulating Bracket, Saving Storage Space.



5. Separation of Inside Power Supplier and Control System Ensures Easy Maintenance.



6. Safe, Convenient and Quick.



7. Power Supplier and Signal Plug Connectors, International Standard.





Description:



1. High Brightness

More than 1500nits and it can be sawn from long distance.



2. Soft Mask

Soft mask design delivers good protection to the players and also decreases damage to LEDs.



3. Adjustable Support and Quick Rigging System

Flexible support design makes LED panel lean by multi angles to cater audience’s needs and quick rigging system design makes the installation and dismantle easier and faster.



4. Cost Effective LED Display

Energy saving design, help you saving cost.

5. Waterproof and 2 Year Warranty

Water Proof IP43 and 2 year warranty. LED display can work in all-weather condition very well.







Applications:

Any indoor sport tadium, such as volleyball, baseball, basketball etc.







Specifications:



Product Series	S6
Pixel Pitch	6mm
Pixel Package	SMD3528
LED Configuration	1R1G1B
Pixel Density	40,000 Pixels/㎡
Module Size	192mm x 192mm
Module Resolution	32 x 32 dots
Suggested Cabinet Size	960mm x 960mm x 150mm
Cabinet Resolution	160 x 160 dots
Cabinet Material	Iron / Aluminum
Brightness	≥ 1500 nits
Color Temperature	3000-12000K
Viewing Angle	H-140°/ V-140°
Driving Mode	1/8
Refresh Rate	1920-3840Hz
Frame Frenquency	60Hz
Grey Level	4096~65536
Number of Color	＞1 billion
Maximum Power Consumption	350 W/㎡
Average Power Consumption	120~180 W/㎡
Input Voltage	AC220±10%, AC110 ±10%
Input Frequency	50-60Hz
External Interface	S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc
IP Rating	IP31





Service & Support:



Two-year quality warranty with lifelong maintenance.



Free guarantee repair (including labor and material); free repair service during the quality warranty period and reasonable charge for spare parts and maintaining service after the quality warranty period. We will never exempt our responsibilities on product owned defects.



Responding time: upon receiving user’s notification, we ensure 24-hour after-sales technical support.



Spare parts: necessary spare parts are provided together with products to customers.



Free technical training: integrative and normative technology training is available for free to customers by our technical personnel to ensure they are skilled in regular operations of hardware and software of products and they are able to estimate and solve small problems.



Telephone investigation: our after-sales team will phone the user every month during the warranty period to follow up the working condition of the products, and to discover and solve problems, if necessary.







Why Choose SAGE?



1. 14 years experienced led display manufacturer since 2002.



2. Multi International Sports Events perimeter display designated supplier, TBF, CBA, WCBA, CUBA, Chinese Football Super League etc.



3. All imports of machinery, strict production process and reliable after-sale services.



4. Using 3A quality accessories and raw materials, free maintenance during warranty period.



5. Leading technologies in display industry, experienced technique team, own multi patent designs.



6. Two years warranty and free online technical support.



7. Good quality products with CE,ETL,ROHS,ISO certified.
